| General | |
| CPU | Dual Intel® Xeon® Scalable Processors, Socket LGA-3647 (Socket P0), each processor supports Intel® Ultra Path Interconnect (UPI) of up to 10.4 GT/s |
| Chipset | Intel® C620 Series (C622/C624/C628) |
| Memory | DDR4-2666/2400/2133, 16*DIMM, up to 2TB, support ECC |
| Storage | 1*M.2 (Key-M, PCIe x4 NVMe SSD, 2242/2260/2280) 12*SATA 3.0 (SAS1~3), 2*SATA 3.0 (SATA 7P) |
| Expansion Interface | 4*PCIe 3.0 x16, 1*PCIe 3.0 x8 |
| BIOS | AMI UEFI BIOS |
| System | Linux, Windows Server 2016, Windows10 |
| I/O Interface | |
| Ethernet | DualLAN with Intel® X550 10GBase-T Ethernet Controller, 2*RJ45 1*Realtek® 1Gbps PCIe Ethernet Controller, RJ45 |
| Serial | 1*RS232 |
| USB | 2*USB 3.0, 4*USB 2.0 |
| Audio | Realtek® ALC662 5.1 channel HDA Codec, with MIC/Line-out |
| Display | |
| Display Interface | 1*VGA: max resolution up to 1920*1080@60Hz |
| Multiple Display | Single |
| Mechanical & Environment | |
| Dimension | 330*305mm |
| Power Input | ATX PSU |
| Temperature | Operation: 0℃~60℃, Storage: -25℃~75℃ |
| Relative Humidity | Operation: 10%~90%, Storage: 5%~95%, non-condensing |
